Features

• Gas tilting Bratt Pan, NG 50Hz, motorized with stainless steel tank of 90 L, 900 range
• Laser-cut joints, automatic welding, and polishes. Screws are hidden from view
• Pan is designed with rounded corners and no edges, and with a wide opening for unloading, making all cooking and cleaning operations easier
• Flange around the perimeter to stop any condensed water from spilling over
• The bottom of the wells is very thick (8 mm for iron pans and 10 mm for stainless steel pans), guaranteeing even heat distribution
• Pans filled with water by means of an electric valve operated with a switch on the front of the machine. The filling pipe is located at the back of the machine
• Double-walled lid with drainer at the back to redirect water of condensation back into the well
• Lid balance system by springs. Compensation system to avoid heavy falls. Can be regulated, with the same system for all modules
• Micro breaking switch halts heating when the pan is raised
• High-temperature enamelled cast iron flue protector
• Access to the components from the front
• Machines with IPX5 grade water protection
• Front access lid handle
• The temperature of the bottom of the pan is controlled by a thermostat, between 50 and 310 °C
• Stainless steel pan
• Electrically heated models use shielded stainless steel heating elements located under the bottom of the pan
• The heating by branched burners or electrical heating elements located in the base of the pan itself, together with the high thickness of the bottom of the pan, ensure maximum uniformity of temperature distribution in all cases, guaranteeing even cooking
• Motorised or crank-operated elevation systems that can raise the pan until it is vertical, to empty it.
• Gas Type: Natural Gas
• Gas power: 18.00kW
• Gas consumption: 1,880 m3/h
• Regulated: NG G20/G25/G25.1 20/25/25 mbar
• Gas diameter 1: R3/4"
• Water inlet diameter: 3/4"

Specifications

Product Video

• Fagor Kore 900 Series Gas Tilting Bratt Pans SB-G910IM
